Thread: Melles Griot LD controller pinout. 06 DLD 105

  1. 04-21-2010, 13:15 #1
    Diachi's Avatar
    Diachi
    Diachi is offline Senior Member
    Join Date
    Jun 2008
    Location
    Yellowknife, NT, Canada
    Posts
    2,147,484,113

    Default Melles Griot LD controller pinout. 06 DLD 105

    Hey Guys,

    Got this LD controller today and I'm wondering what the pinout is. The PSU has two round connectors on the back, one has 6 pins and is labelled "TEC Driver" the other is labelled "LASER/TEC driver" and has 8 pins. There are also two d-sub type connectors, one is 15 pin and is labelled "4-wire LASER/TEC driver" and the other which has 12 pins is labelled "IEEE - 488" (note this only has the shape of a D-sub connector, the contact style is more like one of the ends from a printer cable).

    Three BNC connectors on the front are labelled "EXT IN", "MOD IN" and "OUTPUT", although I assume the output is for connecting an o-scope or something along those lines to monitor the two inputs.

    Any help would be greatly appreciated, thanks!

    Failing any results here I think an e-mail to Melles would be in order?

    Regards,

    Adam
    Reply With Quote Reply With Quote
  2. 04-21-2010, 15:08 #2
    mixedgas's Avatar
    mixedgas
    mixedgas is offline Creaky Old Award Winning Bastard Technologist
    Infinitus Excellentia Ion Laser Dominatus
    Join Date
    May 2007
    Location
    A lab with some dripping water on the floor.
    Posts
    10,067

    Default

    Three BNC connectors on the front are labelled "EXT IN", "MOD IN" and "OUTPUT", although I assume the output is for connecting an o-scope or something along those lines to monitor the two inputs.

    Any help would be greatly appreciated, thanks!

    Failing any results here I think an e-mail to Melles would be in order?

    Jeeze, that sounds like a OEM driver we have on our bench, got pics?

    Steve
    Qui habet Christos, habet Vitam!
    I should have rented the space under my name for advertising.
    When I still could have...
    Reply With Quote Reply With Quote
  3. 04-21-2010, 15:13 #3
    krazer
    krazer is offline Senior Member
    Join Date
    May 2009
    Location
    UCSB
    Posts
    715

    Default

    The IEE-488 is the standard for for GP-IB or HP-IB (general purpose interface bus or hewlett-packard interface buss-they are both the same thing electrically) and is a way to control the supply remotely from a computer (assuming you know the command structure).

    As to the pinouts of the laser/tec connectors I can't help much, but there is a similar sounding driver in the for sale/trade section right now that might share the same pinout, you might try contacting them.
    Last edited by krazer; 04-21-2010 at 15:13. Reason: typo
    Reply With Quote Reply With Quote
  4. 04-21-2010, 15:28 #4
    HD58PHD
    HD58PHD is offline Member
    Join Date
    Feb 2010
    Location
    Utah
    Posts
    96

    Default

    If it's similar to mine,06-DLD-003,I have a copy of the manual if it's compatible.
    Let me know if it will help.
    Mike
    Reply With Quote Reply With Quote
  5. 04-22-2010, 05:00 #5
    Diachi's Avatar
    Diachi
    Diachi is offline Senior Member
    Join Date
    Jun 2008
    Location
    Yellowknife, NT, Canada
    Posts
    2,147,484,113

    Default

    Reply With Quote Reply With Quote
  6. 04-22-2010, 05:11 #6
    Diachi's Avatar
    Diachi
    Diachi is offline Senior Member
    Join Date
    Jun 2008
    Location
    Yellowknife, NT, Canada
    Posts
    2,147,484,113

    Default



    not at home just now, will take more images if needed.

    Mike, those manuals might be helpful. I'll pm you my email address later on.

    Cheers!

    Adam
