Thread: Show off your Laser projector !

  1. 07-28-2009, 10:33 #1
    ExideGlow's Avatar
    ExideGlow
    ExideGlow is offline Senior Member
    Join Date
    Jan 2009
    Location
    Norway, Mo i Rana
    Posts
    127

    Laser Warning Show off your Laser projector !

    Show off your Laser projector

    Well i start.
    here is mine RGB projector.







    300mW 473 LaserWave
    500mW 532 LaserWave
    400mW 637 Medialas
    450mW 660 Maxyz Moduls
    DT 40 Pro Galvo
    Medialas Usb Interface + Mamba black.
    Last edited by ExideGlow; 07-28-2009 at 11:19.
    My Project:
    http://www.photonlexicon.com/forums/showthread.php/7982-ExideGlow-s-NEW-RGB-projector-case?highlight=exideglow%27s

    www.laser-wave.co.uk !
    Reply With Quote Reply With Quote
  2. 07-28-2009, 10:56 #2
    danielbriggs's Avatar
    danielbriggs
    danielbriggs is offline Senior Member
    Join Date
    Dec 2007
    Location
    Nottingham, UK
    Posts
    2,849

    Default

    Here's mine:

    (I don't think I've updated my build thread yet. I've got a trillion photos to post)
    It's still a work in progress. Needs a few things still to do. (such as side panels!) And I should be getting 200mW of 473nm in a couple of weeks.

    300mW 532nm LaserWave
    250mW 660nm Homebrew PBS setup (Using brass LaserWave modules)
    DT25 Galvos (with large mirrors)
    Pangolin FB3-XE + LivePro

    I'd really like to get some 640nm in there to boost the red, and perhaps upgrade to the DT40's in the near future...

    Cheers,
    Dan
    Attached Images Attached Images
    - There is no such word as "can't" -
    - 60% of the time it works every time -
    Reply With Quote Reply With Quote
  3. 07-28-2009, 13:26 #3
    Doc's Avatar
    Doc
    Doc is offline Senior Member
    Join Date
    Dec 2008
    Location
    Southport, UK
    Posts
    2,746

    Default

    A little space here waiting for Mr Red number 2





    http://img62.imageshack.us/img62/3985/laser.gif

    Doc's website

    The Health and Safety Act 1971

    Recklessly interfering with Darwin’s natural selection process, thereby extending the life cycle of dim-witted ignorami; thus perpetuating and magnifying the danger to us all, by enabling them to breed and walk amongst us, our children and loved ones.




    Reply With Quote Reply With Quote
  4. 07-28-2009, 15:06 #4
    platinum's Avatar
    platinum
    platinum is offline *This space intentionally left blank*
    Join Date
    Aug 2007
    Location
    Portland
    Posts
    1,355

    Default

    I love the triangular projector design! That's veritably badass!

    -Jonathan
    Reply With Quote Reply With Quote
  5. 07-29-2009, 01:05 #5
    White-Light
    White-Light is offline Senior Member
    Join Date
    Aug 2008
    Location
    UK
    Posts
    5,704

    Default

    Some very nice projectors there.

    Daniel, I agree with Platinum, that case looks sexy.
    Reply With Quote Reply With Quote
  6. 07-29-2009, 01:21 #6
    Things
    Things is offline Senior Member
    Join Date
    Nov 2007
    Location
    Cairns, Australia
    Posts
    1,896

    Default

    http://files.getdropbox.com/u/203420/Scanner/index.html

    Is mine ATM. It has a "150mW" lasercentury green in it, which actually does over 230mW on startup. And a FB3

    Thats it for now, though hopefully gonna add a red soon.
    Reply With Quote Reply With Quote
  7. 07-29-2009, 04:08 #7
    ledfreak3d's Avatar
    ledfreak3d
    ledfreak3d is offline Senior Member
    Join Date
    May 2007
    Location
    The Netherlands
    Posts
    291

    Default

    Daniel

    where did u get that temperature meter thats in your case that thing is so cool
    Do not look into laser with remaining eye
    Need laser repair contact me !!!!!!
    Reply With Quote Reply With Quote
  8. 07-29-2009, 05:50 #8
    danielbriggs's Avatar
    danielbriggs
    danielbriggs is offline Senior Member
    Join Date
    Dec 2007
    Location
    Nottingham, UK
    Posts
    2,849

    Default

    Cheers for all your comments

    I bought a couple of those meters, and currently have that one hooked up to the galvo amp heatsink, as that used to get a bit warm.

    They were a few quid off eBay from some Chinese seller: http://cgi.ebay.co.uk/Digital-Thermo...d=p3286.c0.m14

    Cheers,
    Dan
    - There is no such word as "can't" -
    - 60% of the time it works every time -
    Reply With Quote Reply With Quote
  9. 07-30-2009, 03:40 #9
    Lazerjock's Avatar
    Lazerjock
    Lazerjock is offline Senior Member
    Join Date
    Sep 2008
    Location
    Orlando, Florida
    Posts
    1,206

    Default

    Here is my build. The idea is that it is all self contained in its road case. I show up with my road case and a laptop. Plug in the USB cable and I'm done with set up.

    It has Cambrige 6800 scanners driven by a Turbo Track amp.
    I'm using a sound card DAC.
    I found a sweet little 16 channel board to convert USB to TTL so I can drive my GM20's for beam pickoffs for the Lumia and Machita gratting.

    I'm getting almost 300mw out of R, G & BR.

    All of the posts, stand offs, base plate are hand made as well as the heat sinks for the 650 & BR's .
    Reply With Quote Reply With Quote
  10. 07-30-2009, 11:40 #10
    Laserman532's Avatar
    Laserman532
    Laserman532 is offline Senior Member
    Join Date
    Nov 2007
    Location
    Bend Oregon USA
    Posts
    3,350

    Default

    cool lazerjock...very 007 of you!
    Pat B

    laserman532 on ebay

    Been there, done that, got the t-shirt & selling it in a garage sale.
    Reply With Quote Reply With Quote
